Introduction
61-900040-000 Rev. Date: 01/22 2-5
2.3 SPECIFICATIONS, DIMENSIONS, AND CAPACITIES
Table 2- 1 below provides the electrical use, machine weight and dimensions, and tank
capacities of the Phoenix LT4 Lane Machine.
Table 2- 1
Single phase, 50/60 Hertz 1860 watts
110 V (US) 15.5 AMP
200 – 240V (other countries) Aµ 6 AI
p
9.4
Main Power Circuit Breaker
on Control Box
20 amp protection (110V), 14 amp protection (220V)
Each motor and solenoid is individually protected against an
overcurrent condition either by a thermal overload protection
device or a fuse.
The Machine must be operated on a dedicated and
grounded electrical circuit.
13.93 inches (35.4 cm) H x 35.6 inches (90.4 cm) L x 55.48
inches (140.9 cm) W
3-conductor, 110V, 12 AWG (US), 220V, 14 AWG (2.5 mm
2
harmonized), 125 feet (38.1 m) L
1.75 gallons (6.62 liters), enough to clean approximately 16
lanes from the on-approach start position.
Use only cleaners specifically manufactured for use on
bowling lanes.
Holds waste for up to 16 lanes (~5.75L/1.52gal.) when a
defoamer is used.
37.5 ounces (1.11 liters), enough to condition up to 24
lanes. Using patterns with higher oil output may reduce the
number or lanes covered.
Use only oil products specifically manufactured for use
on bowling lanes.
Foams:
Standard
Replacement Foam
Wicks
Outside - 3-1/2 inches (8.9 cm) H x 7.85 inches (19.9 cm) L
Track – 3-1/2 inches (8.9 cm) H x 3 inches (7.6 cm) L
Middle - 3-1/2 inches (8.9 cm) H x 10 inches (25.4 cm) L
The above represents one side (half) of the oil tank. Identical foams are
installed on the other side of the oil tank.
3-1/2 inches (8.9 cm) H x 48 inches (121.9 cm) L
