Phoenix LT4 - Page 130

Phoenix LT4 Lane Machine Operation, Maintenance, and Parts Manual
61-900040-000 Rev. Date 01/22
7-11
Vacuum System
NUMBER
DESCRIPTION
NUMBER
DESCRIPTION
1
04-120
HOSE CLAMP
8
294-116-147
VAC HEAD ASM
2
294-115-113
VAC HOSE ASM
9
294-116-148
EXHAUST DIVERTER
3
294-115-233
WASTE TANK GUARD ASM
10
801-749-081
SCREW, FLANGE HEAD HEX, 1/4-20 X 1/2
4
294-116-031
294-116-032
VAC MOTOR & BRACKET ASM, 110V
VAC MOTOR & BRACKET ASM, 220V
11
809-849-100
SCREW, HEX, 1/4-20 X 5/8
5
294-116-043
TANK SUPPORT ASM
12
843-140-002
NUT, KEPS, 10-32
6
294-116-125
294-116-124
VAC SOLENOID ASM, 110V
VAC SOLENOID ASM, 220V
13
844-049-002
NUT, STOVER LOCK, 1/4-20
7
294-116-128
VAC HEAD TENSIONER ASM
14
SA-1129
WASTE TANK ASM
