Operation
61-900040-000 Rev. Date: 01/22 3-21
Table 3- 6
ID
Component
Description
10
Rear Squeegee
The squeegee glides along the lane surface, wiping up
the emulsified oil/cleaner solution which is then drawn up
into the vacuum head by suction.
11
Agitator Foam
This foam strip mixes the cleaner into the oil on the lane
to improve cleaning efficiency.
11
10
Figure 3- 40
