49. Parking electronic control unit
50. Brake calliper sensor
51. Geared motor
52. Fuel level transmitter
53. «MODE» button
54. Rider presence sensor
55. Locking/unlocking switch
56. Injection load remote control
57. Fuel pump
58. Fuel injector
59. Potentiometer
60. Right wheel revolution sensor
61. Left wheel revolution sensor
62. HV coil
63. Diagnostics socket
64. Revolution sensor
Key
Ar: Orange Az: Sky blue Bi: White Bl: Blue Gi: Yellow Gr:Grey
Ma:Brown Ne: Black Ro: Pink Rs: Red Ve: Green Vi: Purple
Electrical system MP3 400 i.e.
ELE SYS - 4
