20. Saddle opening actuator
21. Saddle opening receiver
22. Starter button
23. Stop button on rear brake
24. Stop button on front brake
25. Turn indicator switch
26. Hazard button
27. Hazard and turn indicator control device
28. Wiring for antitheft device
29. Helmet compartment light switch
30. Helmet compartment light switch
31. Light switch
32. Headlight remote control
33. Helmet compartment internal light
34. Rear left light
A. Rear left turn indicator bulbs
B. Stop light bulb
C. Tail light bulb
35. License plate lamp
36. Rear right light
A. Tail light bulb
B. Stop light bulb
C. Rear right turn indicator bulbs
37. Front left turn indicator light
38. Headlight
A. Tail light bulbs
B. Low beam bulb
C. High beam bulb
39. Front right turn indicator light
40. Pressure sensor
41. Horn remote control
42. Horn
43. Horn button
44. Oil pressure sensor
45. Parking brake button
46. Coolant temperature sensor
47. External temperature sensor
48. Instrument panel
MP3 400 i.e. Electrical system
ELE SYS - 3
