11 / 12 - Diagnostics socket/ main fuses: these
components are found in the helmet compartment.
13 - Lambda probe: The lambda probe is mounted
on the exhaust manifold.
14 - Engine oil pressure sensor: remove the ex-
haust end to reach it.
15 - Centralina comando stazionamento: per ac-
cedervi rimuovere il controscudo.
MP3 400 i.e. Electrical system
ELE SYS - 9
