Piper ARROW III Service Manual

TABLE IV-II
MAXIMUM DISTANCE BETWEEN SUPPORTS FOR FLUID TUBING
TUBE OD DISTANCE BETWEEN SUPPORTS (IN.)
(IN.) ALUMINUM ALLOY STEEL
1/8 9-1/2 11-1/2
3/16 12 14
1/4 13-1/2 16
5/16 15 18
3/8 16-1/2 20
1/2 19 23
5/8 22 25-1/2
3/4 24 27-1/2
1 26-1/2 30
TABLE IV-III. Hose clamp tightening,
(initial installation).
Types of clamps
Types of hose
Worm screw type All other types
Self sealing Finger-tight-plus Finger-tight-plus
2 complete turns 2 1/2 complete turns
All other hose Finger-tight-plus Finger-tight-plus
1 1/4 complete turns 2 complete turns
lf clamps do not seal at specified tightening, examine hose connection and replace parts as necessary.
Added: 5/1/80
1F2
* CHEROKEE ARROW III SERVICE MANUAL
STRUCTURES

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
