Piper ARROW III Service Manual

TABLE II-III. RECOMMENDED ENGINE LUBRICATING OILS
PA-28R-201
Average Average Ambient Oil Inlet Temperatures
Grade Oil Air Temperature Desired Maximum
SAE 50 Above 60°F 180°F 245°F
(16°C) (82°C) (118°C)
SAE 40 30°F to 90°F 180°F 245°F
(-1°C to 32°C) (82°C) (118°C)
SAE 30 0°F to 70°F 170°F 225°F
(-17°C to 20°C) (77°C) (107°C)
SAE 20 Below 10°F 160° F 210°F
(12°C) (71°C) (99°C)
PA-28R-201T
Average Average Ambient
Grade Oil Air Temperature
SAE 50 Above 40°F
SAE 30 or Below 40°F
10-W-30
NOTE
When the average ambient air temperature is approximately at the dividing
line, use the lighter oil.
Revised: 8/31/77
1C2
*CHEROKEE ARROW III SERVICE MANUAL
HANDLING AND SERVICING

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
