Piper ARROW III Service Manual

Aerofiche
Paragraph Grid No.
10-76. Removal and Replacement of Face Mounted Instruments................................................ 2G12
10-77. General .............................................................................................................................. 2G12
10-78. Removal and Replacement of Cluster Mounted Instruments............................................ 2G13
10-79. General .............................................................................................................................. 2G13
10-80. Gyro Fitting Installation Procedure................................................................................... 2G13
10-81. Cylinder Head Temperature Gauge................................................................................... 2G13
10-82. General .............................................................................................................................. 2G13
10-83. Troubleshooting................................................................................................................. 2G14
10-84. Removal and Replacement................................................................................................ 2G14
10-85. Piper Auto Control System................................................................................................ 2G14
10-86. Annunciator Panel............................................................................................................. 2G14
10-87. General .............................................................................................................................. 2G14
10-88. Troubleshooting................................................................................................................. 2G14
10-89. Removal and Replacement................................................................................................ 2G14
Revised: 2/13/89
2F7
INSTRUMENTS

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
