TABLE V-III. TROUBLESHOOTING CHART (SURFACE CONTROLS)
AILERON CONTROL SYSTEM
Lost motion between con- Cable Tension too low. Adjust cable tension.
trol wheel and aileron. (Refer to Paragraph
5-12.)
Linkage loose or worn. Check linkage and
tighten or replace.
Broken pulley. Replace pulley.
Cables not in place on Install cables cor-
pulleys. rectly. Check cable
guards.
Resistance to control System not lubricated Lubricate system.
wheel rotation. properly.
Cable tension too high. Adjust cable tension.
(Refer to Paragraph
5-12.)
Control column hori- Adjust chain tension.
zontal chain improperly (Refer to Paragraph
adjusted. 5-6.)
Pulleys binding or Replace binding pulleys
rubbing. and/or provide clearance
between pulleys and
brackets.
Cables not in place on Install cables cor-
pulleys. rectly. Check cable
guards.
Bent aileron and/or Repair or replace ai-
hinge. leron and/or hinge.
Cables crossed or Check routing of control
routed incorrectly. cables.
Trouble Cause Remedy
Issued: 12/15/76
CHEROKEE ARROW III SERVICE MANUAL
SURFACE CONTROLS

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
