Piper ARROW III Service Manual

1G21
TABLE V-III. TROUBLESHOOTING CHART (SURFACE CONTROLS) (cont.)
STABLIATOR CONTROL SYSTEM (cont.)
Resistance to stabilator System not lubricated Lubricate system.
control movement. properly.
Cable tension too high. Adjust cable tension
per Paragraph 5-16.
Binding control column. Adjust and lubricate
per Paragraph 5-6.
Pulleys binding or Replace binding pulleys
rubbing. and/or provide clearance
between pulleys and
brackets.
Cables not in place on Install cables cor-
pulleys. rectly.
Cables crossed or Check routing of control
routed incorrectly. cables.
Bent stabilator hinge. Repair or replace
stabilator hinge.
Incorrect stabilator Stabilator stops Adjust stop screws per
travel. incorrectly adjusted. Paragraph 5-16.
Correct stabilator Stabilator cables Rig cables in accordance
travel cannot be incorrectly rigged. with Paragraph 5-16.
obtained by adjusting
stops.
Trouble Cause Remedy
Issued: 12/15/76
CHEROKEE ARROW III SERVICE MANUAL
SURFACE CONTROLS

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
