Piper ARROW III Service Manual

TABLE III-I INSPECTION REPORT.
—Note—
Perform all inspections or operations at each of the inspection intervals as
indicated by a circle (O). (See Notes at end of report)
Nature of Inspection
A. PROPELLER GROUP
WARNING
Read Note 28 prior to completing this inspection
group.
1. Inspect spinner and back plate for cracks................................................................. O O O O
2. Inspect blades for nicks and cracks........................................................................... O O O O
3. Inspect for grease and oil leaks................................................................................. O O O O
4. Lubricate propeller per lubrication chart (Refer to
Service Manual, Section II)...................................................................................... O O O O
5. Inspect complete spinner and spinner mounting
bulkheads, for security, chafing, cracks, deterioration,
wear, and correct installation.................................................................................... O O O
6. Inspect propeller mounting bolts and safety (check
torque if safety is broken) ( Refer to Note 16).......................................................... O O O
7. Inspect hub parts for cracks and corrosion ............................................................... O O O
8. Rotate blades of propeller and check for tightness in
hub pilot tube............................................................................................................ O O O
9. Remove propeller and clean sludge from propeller
and shaft.................................................................................................................... O O
10.Inspect complete propeller assembly for security,
chafing, deterioration, wear, and correct installation................................................ O O O
11.Overhaul propeller per manufacturers recommendations (See Notes 5 and 28)......
B. ENGINE GROUP (CONTINENTAL)
WARNING
Read Notes 22, 4, and 28 before completing this
inspection group. When working on engine, ensure
that magneto primary circuits are grounded.
1. Remove the engine cowling...................................................................................... O O O O
2. Clean and inspect cowling for cracks, distortion and
loose or missing fasteners......................................................................................... O O O
3. Drain oil sump while engine is still warm................................................................ O O O
4. Change full flow (spin-on type) oil filter element. Thoroughly inspect element
for foreign particles). Check oil level after installing new filter. (Another check
will be required after engine runup) ......................................................................... O O O O
5. Inspect oil temperature sender unit for leaks and security........................................ O O O O
6. Inspect oil lines, hoses, and fittings for leaks, security, chafing, dents
and cracks (Read Note 6).......................................................................................... O O O O
50 500 1000100
Inspection Time (Hrs)
CHEROKEE ARROW III SERVICE MANUAL
1D4
Revised: 2/13/89 INSPECTION

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
