Piper ARROW III Service Manual

2F3
TABLE VIX-IV. TROUBLESHOOTING CHART. (FUEL SYSTEM)
Failure of fuel to flow. Fuel line blocked. Flush fuel system.
Fuel vent cap blocked. Check and clean vent
hole in cap.
Mechanical or electrical Check and replace if
fuel pump failure. necessary.
Fuel selector valve in Reposition as required.
improper position.
Damaged fuel selector Replace fuel selector
valve. valve.
Fuel quantity gauge Broken wire. Check and repair.
fails to operate.
Gauge inoperative. Replace gauge.
Circuit breaker open. Check and reset.
Float and arm assembly Check.
of fuel sender sticking.
Bad ground. Check for good contact
at ground lip or rear of
gauge.
Trouble Cause Remedy
Revised: 2/13/89
CHEROKEE ARROW III SERVICE MANUAL
FUEL SYSTEM

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
