Piper ARROW III Service Manual

1L6
TABLE VII-II. TROUBLESHOOTING CHART (LANDING GEAR) (cont)
Nose gear fails to steer Steering arm roller Replace defective
properly. (cont) sheared at top of roller.
strut.
Steering bellcrank loose Readjust and tighten.
on attachment plate.
Steering bellcrank Replace bearing
bearing and/or bolt and/or bolt.
worn.
Shimmy dampener Replace.
galling or binding.
Nose gear fails to Steering arm roller Replace defective
straighten when sheared at top of roller.
landing gear extends. strut.
Incorrect rigging of Check nose gear
nose gear steering. steering adjustment.
Nose gear fails to Centering guide roller Replace roller.
straighten when sheared.
landing gear retracts.
Damaged guide. Replace guide.
Main landing shimmies Tire out of balance. Check balance and replace
during fast taxi, takeoff, tire if necessary.
or landing.
Worn or loose wheel Replace and/or adjust
bearings. wheel bearings.
Worn torque link bolts Replace bolts and/or
and/or bushings. bushings.
Trouble Cause Remedy
Revised: 2/13/89
CHEROKEE ARROW III SERVICE MANUAL
HYDRAULIC SYSTEM

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
