Piper ARROW III Service Manual

1L8
TABLE VII-II. TROUBLESHOOTING CHART (LANDING GEAR) (cont)
Red gear unsafe light and Warning light and horn Check wiring.
horn fail to operate when circuit wire broken.
selector is moved to up
position with gear extended
and throttle retarded.
Above condition on Defective safety (squat) Replace switch.
ground. switch.
Above condition in Pressure switch open. Replace switch.
the air.
Hydraulic pump shuts Gear not fully Determine cause and
off, but red gear unsafe retracted. remedy.
light remains on.
Trouble Cause Remedy
Revised: 2/13/89
CHEROKEE ARROW III SERVICE MANUAL
HYDRAULIC SYSTEM

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
