2I20
TABLE XI-V. ELECTRICAL SYSTEM TROUBLESHOOTING (cont)
Excessive ammeter Excessive resistance in Check all connections and
fluctuation. field circuit. wire terminals in field
circuit for deterioration
such as loose binding posts,
broken wire strands at
terminals, etc. Tighten all
connections and replace
faulty terminals.
High field circuit If problem persists, jump
resistance. across terminals of the
following components
one at a time until the
faulty unit is isolated.
a. Field 5 amp (alternator)
circuit protector.
b. Alternator half of
master switch.
c. Overvoltage relay.
Defective voltage Replace voltage regulator.
regulator.
Trouble Cause Remedy
Revised: 2/13/89
CHEROKEE ARROW III SERVICE MANUAL
ELECTRICAL SYSTEM
ALTERNATOR (cont)
