Piper ARROW III Service Manual

The following is a complete listing of Piper A.F.C.S. equipment service literature. It is imperative to correctly
identify the Autopilot system by “faceplate” model name in order to consult the appropriate service manual.
Each manual identifies the revision level and revision status as called out on the Master Parts Price List-
Aerofiche published monthly by Piper. Consult the aircraft’s parts catalog for replacement parts.
NAME PIPER PART NO.
AutoControl I/II and AltiMatic I/II 753 798
AutoControl III and AltiMatic III and IIIB 753 723
AutoControl IIIB and AltiMatic IIIB-1 761 502
AltiMatic IIIC 761 602
AltiMatic V and V-1 761 525
AltiMatic V F/D and V F/D-1 761 526
AltiMatic X F.D./A.P. & X.A.P. 761 668
AutoFlite 753 720
AutoFlite II 761 481
Piper Pitch Trim (Manual-Electric) 757 771
Revised: 2/13/89
2J21
CHEROKEE ARROW III SERVICE MANUAL
ELECTRONICS

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
