Piper ARROW III Service Manual

TABLE III-I INSPECTION REPORT (cont)
Nature of Inspection
B. ENGINE GROUP (CONTINENTAL) (cont.)
29.Inspect condition and operation of fuel pumps (engine driven and electric) ........... O O O
30.Overhaul or replace engine-driven fuel pumps per manufacturer’s
recommendations (Read Note 5) ..............................................................................
31.Overhaul or replace electric fuel pump as required ................................................. O
32.Inspect hoses, wires, clamps, condition, and operation of vacuum pump(s)
(engine-driven and auxiliary electrically-driven) (Read Note 25) ........................... O O O
33.Replace engine or electrically driven vacuum pump(s) (Read Note(s) 5 and 25).... O
34.Inspect throttle, alternate air, mixture, and propeller controls for security, travel,
and operating condition ............................................................................................ O O O
35.Inspect exhaust stacks, connections, and gaskets (Replace gaskets as required) .... O O O O
36.Inspect breather tubes for obstructions and security................................................. O O O
37.Inspect crankcase for cracks, leaks, and security of seam bolts............................... O O O
38.Inspect engine mounts for cracks and loose ............................................................ O O O
39.Inspect rubber engine mount bushings for deterioration (replace as reqd.) or at
engine overhaul ........................................................................................................ O O O
40.Inspect all engine baffles and seals........................................................................... O O O
41.Inspect fire wall seals................................................................................................ O O O
42.Inspect condition of alternator and starter ................................................................ O O O
43.Inspect all lines, hoses, air ducts, electrical leads, and engine attachments for
security, proper routing, chafing, cracks, deterioration and correct installation
(Refer to latest Piper Service Bulletin 561).............................................................. O O O O
44.Check air conditioner compressor oil level (Read Note 13)..................................... O O O
45.Inspect condition and tension of compressor drive belt (Refer to Service
Manual, Section XIV) .............................................................................................. O O O
46.Inspect security of compressor mounting................................................................. O O O
47.Inspect compressor clutch security, wiring, and condition....................................... O O O
48.Check fluid in brake reservoir (Fill as required) ...................................................... O O O O
49.Overhaul or replace propeller governor per manufacturer’s recommendations.
(Refer to latest revision of Hartzell Letter 61)..........................................................
50 500 1000100
Inspection Time (HRS)
CHEROKEE ARROW III SERVICE MANUAL
1D6
Revised 2/13/89 INSPECTION

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
