User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
 ARP Param
eters
The ARP parameters can be configured when Frame Type "ARP" is selected.
Object Description
Specif
y the available ARP/RARP opcode (OP) flag for this ACE.
■ Any: No ARP/RARP OP flag is specified. (OP is "don't-care".)
■ ARP: Frame must have ARP/RARP opcode set to ARP.
■ RARP: Frame must have ARP/RARP opcode set to RARP.
■ Other: Frame has unknown ARP/RARP Opcode flag.
 ARP/RARP
Specif
y the available ARP/RARP opcode (OP) flag for this ACE.
■ Any: No ARP/RARP OP flag is specified. (OP is "don't-care".)
■ Request: Frame must have ARP Request or RARP Request OP flag set.
■ Reply: Frame must have ARP Reply or RARP Reply OP flag.
 Request/Reply
Specif
y the sender IP filter for this ACE.
■ Any: No sender IP filter is specified. (Sender IP filter is "don't-care".)
■ Host: Sender IP filter is set to Host. Specify the sender IP address in the
SIP Address field that appears.
■ Network: Sender IP filter is set to Network. Specify the sender IP address
and sender IP mask in the SIP Address and SIP Mask fields that appear.
 Sender IP
Filt
er
When "Host" or
"Network" is selected for the sender IP filter, you can enter a
specific sender IP address in dotted decimal notation.
 Sender IP Address
When "Net
work" is selected for the sender IP filter, you can enter a specific
sender IP mask in dotted decimal notation.
 Sender IP Mask
Specif
y the target IP filter for this specific ACE.
■ Any: No target IP filter is specified. (Target IP filter is "don't-care".)
■ Host: Target IP filter is set to Host. Specify the target IP address in the
Target IP Address field that appears.
■ Network: Target IP filter is set to Network. Specify the target IP address
and target IP mask in the Target IP Address and Target IP Mask fields that
appear.
 T
arget IP Filter
When "Host" or
"Network" is selected for the target IP filter, you can enter a
specific target IP address in dotted decimal notation.
 Target IP Address
When "Net
work" is selected for the target IP filter, you can enter a specific target
IP mask in dotted decimal notation.
 Target IP Mask
 ARP Sender MAC
Match
Specify whether frames can hit the action according to their sender hardware
address field (SHA) settings.
■ 0: ARP frames where SHA is not equal to the SMAC address.
■ 1: ARP frames where SHA is equal to the SMAC address.
■ Any: Any value is allowed ("don't-care").
215
