y whether frames can hit the action according to their target hardware
address field (THA) settings.
■ 0: RARP frames where THA is not equal to the SMAC address.
■ 1: RARP frames where THA is equal to the SMAC address.
■ Any: Any value is allowed ("don't-care").
 RARP Target MAC
Match
Specif
y whether frames can hit the action according to their ARP/RARP
hardware address length (HLN) and protocol address length (PLN) settings.
■ 0: ARP/RARP frames where the HLN is equal to Ethernet (0x06) and the
(PLN) is equal to IPv4 (0x04).
■ 1: ARP/RARP frames where the HLN is equal to Ethernet (0x06) and the
(PLN) is equal to IPv4 (0x04).
■ Any: Any value is allowed ("don't-care").
 IP/Ethernet Length
Specif
y whether frames can hit the action according to their ARP/RARP
hardware address space (HRD) settings.
■ 0: ARP/RARP frames where the HLD is equal to Ethernet (1).
■ 1: ARP/RARP frames where the HLD is equal to Ethernet (1).
■ Any: Any value is allowed ("don't-care").
 IP
Specif
y whether frames can hit the action according to their ARP/RARP protocol
address space (PRO) settings.
■ 0: ARP/RARP frames where the PRO is equal to IP (0x800).
■ 1: ARP/RARP frames where the PRO is equal to IP (0x800).
■ Any: Any value is allowed ("don't-care").
 Ethernet
 IP Parameters
The IP parameters can be configured when Frame Type "IPv4" is selected.
Object Description
 IP Protocol Filter
Specify the IP protocol filter for this ACE.
■ Any: No IP protocol filter is specified ("don't-care").
■ Specific: If you want to filter a specific IP protocol filter with this ACE,
choose this value. A field for entering an IP protocol filter appears.
■ ICMP: Select ICMP to filter IPv4 ICMP protocol frames. Extra fields for
defining ICMP parameters will appear. These fields are explained later in
this help file.
■ UDP: Select UDP to filter IPv4 UDP protocol frames. Extra fields for
defining UDP parameters will appear. These fields are explained later in
this help file.
■ TCP: Select TCP to filter IPv4 TCP protocol frames. Extra fields for defining
TCP parameters will appear. These fields are explained later in this help
file.
216
