User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
Specif
y the hop limit settings for this ACE.
■ zero: IPv6 frames with a hop limit field greater than zero must not be able
to match this entry.
■ non-zero: IPv6 frames with a hop limit field greater than zero must be able
to match this entry.
■ Any: Any value is allowed ("don't-care”).
 Hop Limit
 ICMP Parameters
Object Description
Specif
y the ICMP filter for this ACE.
■ Any: No ICMP filter is specified (ICMP filter status is "don't-care").
■ Specific: If you want to filter a specific ICMP filter with this ACE, you can
enter a specific ICMP value. A field for entering an ICMP value appears.
 ICMP
Type Filter
When "S
pecific" is selected for the ICMP filter, you can enter a specific ICMP
value.
The allowed range is 0 to 255. A frame that hits this ACE matches this ICMP
value.
 ICMP Type Value
Specif
y the ICMP code filter for this ACE.
■ Any: No ICMP code filter is specified (ICMP code filter status is
"don't-care").
■ Specific: If you want to filter a specific ICMP code filter with this ACE, you
can enter a specific ICMP code value. A field for entering an ICMP code
value appears.
 ICMP
Code Filter
When "S
pecific" is selected for the ICMP code filter, you can enter a specific
ICMP code value.
The allowed range is 0 to 255. A frame that hits this ACE matches this ICMP
code value.
 ICMP Code Value
 TCP/UDP Parameters
Object Description
 TCP/UDP Source Filter
Specify the TCP/UDP source filter for this ACE.
■ Any: No TCP/UDP source filter is specified (TCP/UDP source filter status
is "don't-care").
■ Specific: If you want to filter a specific TCP/UDP source filter with this
ACE, you can enter a specific TCP/UDP source value. A field for entering a
TCP/UDP source value appears.
219
