User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
■ Range: If you want to filter a specific TCP/UDP source range filter with this
ACE, you can enter a specific TCP/UDP source range value. A field for
entering a TCP/UDP source value appears.
 TCP/UDP Source No.
When "Specific" is selected for the TCP/UDP source filter, you can enter a
specific TCP/UDP source value. The allowed range is 0 to 65535. A frame that
hits this ACE matches this TCP/UDP source value.
When "Ra
nge" is selected for the TCP/UDP source filter, you can enter a specific
TCP/UDP source range value. The allowed range is 0 to 65535. A frame that hits
this ACE matches this TCP/UDP source value.
 TCP/UDP Sourc
e
Range
 TCP/UDP Destination
Filter
Specify the TCP/UDP destination filter for this ACE.
■ Any: No TCP/UDP destination filter is specified (TCP/UDP destination filter
status is "don't-care").
■ Specific: If you want to filter a specific TCP/UDP destination filter with this
ACE, you can enter a specific TCP/UDP destination value. A field for
entering a TCP/UDP destination value appears.
■ Range: If you want to filter a specific range TCP/UDP destination filter with
this ACE, you can enter a specific TCP/UDP destination range value. A
field for entering a TCP/UDP destination value appears.
 TCP/UDP Destination
Number
When "Specific" is selected for the TCP/UDP destination filter, you can enter a
specific TCP/UDP destination value. The allowed range is 0 to 65535. A frame
that hits this ACE matches this TCP/UDP destination value.
 TCP/UDP Destination
Range
When "Range" is selected for the TCP/UDP destination filter, you can enter a
specific TCP/UDP destination range value. The allowed range is 0 to 65535. A
frame that hits this ACE matches this TCP/UDP destination value.
Specif
y the TCP "No more data from sender" (FIN) value for this ACE.
■ 0: TCP frames where the FIN field is set must not be able to match this
entry.
■ 1: TCP frames where the FIN field is set must be able to match this entry.
■ Any: Any value is allowed ("don't-care").
 TCP FIN
Specif
y the TCP "Synchronize sequence numbers" (SYN) value for this ACE.
■ 0: TCP frames where the SYN field is set must not be able to match this
entry.
■ 1: TCP frames where the SYN field is set must be able to match this entry.
■ Any: Any value is allowed ("don't-care").
 TCP SYN
 TCP RST
Specify the TCP "Reset the connection" (RST) value for this ACE.
■ 0: TCP frames where the RST field is set must not be able to match this
entry.
■ 1: TCP frames where the RST field is set must be able to match this entry.
■ Any: Any value is allowed ("don't-care").
220
