Polaris IQ 2007 - Page 16

1.13
Model Specifications
1
Front Suspension
Suspension Type IQ 42.5
Shocks
Ryde FX Gas Bag
Compression Adjustable
IFS Spring Rate
lbs/in (N/mm)
120 (21)
Spring Installed Length
Inches (cm)
9.95 (25.3)
Front Vertical Travel
Inches (cm)
9.92 (25.2)
Ski Center Distance
Inches (cm)
42.5 (108)
Camber Inches (cm) 2.25 ± 0.31 (57 ± 7.9)
Toe Out Inches (cm) 0 - 0.12 (0 - 0.31)
Rear Suspension
Suspension Type Fast M-10 128
Front Track Shock (FTS) Ryde FX Gas Bag
FTS Spring Rate
lbs/in (N/mm)
180 (31)
FTS Spring Installed
Length Inches (cm)
8.5 (21.6)
Rear Track Shock (RTS)
Fox HPG w/IFP
(Rebuildable)
Lower Outer Spring Rate
lbs/in (N/mm)
715 (125)
Lower Inner Spring Rate
lbs/in (N/mm)
425 (74.4)
Upper Spring Rate
lbs/in (N/mm)
273 (48)
Rear Travel Inches (cm) 13 (33)
