USER MANUAL
URM18PH392 Rev A. May 2020 Page 51 of 86
Example Scenario: SENSOR ORIGIN
Your project is a multi-player game that uses 16 FT-Sensors and 4 VIPERâ„¢ Sources over an expanded
tracking area.
The SOURCE CONFIGURATION command is applied to establish the position and rotation of each source
relative to a Common Origin.
You want each Sensor to use the expanded tracking area afforded by detecting the EM fields of all the
Sources, BUT you do not want the P&O to be relative to the Common Origin.
Instead, you want to configure each player-group of 4 Sensors to use a different Source as the P&O
reference, with one Sensor in the group using the Common Origin.
Use the SENSOR ORIGIN command to configure the P&O reference of each sensor in each group of
four.
