Parameter Reference
71
X_XsiServer Host name or IP address of the Broadsoft XSI
application server.
X_XsiServerPort Listening port of the Broadsoft XSI application
server. If not specified or 0, the default ports are 80
for HTTP and 443 for HTTPS.
0
X_XsiServerScheme Scheme to access the Broadsoft XSI application
server.
HTTP
UserAgentDomain CPE domain string. If empty, device uses
ProxyServer as its own domain to form its AOR
(Address Of Record) or Public Address when
constructing SIP messages (for example, in the
FROM header of outbound SIP Requests).
Note: If SPn Service::URI is specified, additional
rules applied in forming the AOR. See the
description of the URI parameter for more details and
examples.
OutboundProxy Host name or IP address of the outbound proxy.
Outbound proxying is disabled if this parameter is
blank.
OutboundProxyPort Destination port to be used in connecting to the
outbound proxy.
5060
X_OutboundProxyTransport Controls the SIP transport for the outbound proxy
server, which can be different from that of the proxy
server. Choose from:
• UDP
• TCP
• TLS
• Follow ProxyServerTransport
Follow
ProxyServerTransp
ort
X_UserAgentContactFollowPr
oxyServerTransport
If enabled, the user agent uses a Contact and Via
transport that agrees with ProxyServerTransport.
No
X_BypassOutboundProxyInC
all
Enables bypassing the OutboundProxy inside the
SIP dialog.
No
RegistrationPeriod Nominal interval between device register in seconds. 60
X_RegistrationMargin Number of seconds before current registration
expires that the device should re-Register (for
example, 5 seconds). If value is less than one, it is
interpreted as a fraction of the current expires value
(for example, 0.1 of 60 seconds is 6 seconds). If
value is 0 or blank, the device determines a proper
margin on its own.
TimerT1 Value of SIP timer T1 in ms. 500
ITSP Profile X – SIP Web Page (X = A, B, C, D, E, F, G, H) Settings Parameter Guide
Parameter Description Default Setting
