Page #14 background image
Polycom KIRK Wireless Server 8000 and KIRK Wireless Server 2500 Configuration Guide KIRK Wireless Server 8000 and KIRK
9 Polycom, Inc.
Table 2-4 Analogue Interface Card LEDs
Table 2-5 Base Station Interface Card
LED Name Location Color Description
Ringing Connectors on
analogue
interface cards
Yellow Steady yellow
when there’s
incoming ringing
voltage for at least
one line.
Activity Connectors on
analogue
interface cards
Green Steady green
when the card is
up and running.
Also indicates that
there are no
active calls.
Slow green flash
when there’s at
least one active
call on the
connector.
LED Name Location Color Description
RFP 0-7 Upper half - one
LED for each RFP
Red Steady red when
there is power on
the connector but
not active RFP
connect.
Flashing red
during power up
sequence of RFP.
RFP 0-7 Upper half - one
LED for each RFP
Green Steady green
when RFP is in
sync.
Flashing green
when at least one
handset has a
connection on the
RFP.
