Polycom KIRK Wireless Server 8000 & KIRK Wireless Server 2500 Configuration Guide Base Station Settings
53 Polycom, Inc.
Base Station Settings
On the Base Stations menu you find information about the settings of each base
station in the system.
Figure 6-3 List Base Stations tab
To Read Base Station Settings
a To populate the table with system information, click the List Base Station
tab.
The following information is displayed.
Table 6-2 Base Station Settings
Parameter Description
RFP Radio Fixed Part number 0-511
PCS The base station software version
Part Number Part number that identifies the base
station software.
Region The region that determines the base
station settings.
Time slot in air There are 12 air time slots in each
direction (numbered 0-11). If set to “Even”,
the base station uses an even time slot
(0,2,4,6,8,10). If set to “Odd” then the
base station will use an odd time slot
(1,3,5,7,9,11). If set to “Follow RPN”, the
base station will use even time slots if it
has an even RPN; if it has an odd RPN
then the base station will use odd time
slots.
RPN in Air Radio Part Number in Air. The number the
base station sends. (0-255) For more
information, see “Radio Part Numbers” on
page 54
Cable Delay The time it takes the signal to reach the
base station.
Shelf The number of the shelf to which the base
station is connected. (1-8)
Card No. Specifies the card number. (1-8)
