Polysoude P6 - Display Messages: Out of Cycle and During Cycle

THE ART OF WELDING
P6
52-92 PN-0509076 Rev. 16
Display messages4. 5. 5. 1.
Examples of displayed messages out of weld cycle:
Switching on
-- POLYSOUDE ---
.....
End of installation
>WP :001IN170x15
PRG:<03ABCDEFG>
F r i 05 Jan 2007
11:49
Example of fault message
WP :001 IN170x15
PRG:<03ABCDEFG>
ROTATION: 04241
*!* Speed Regul
.
WP :001 IN170x15
PRG:<03ABCDEFG>
Ga s 1 / 2 OK /NOK
Water= 0.8L/min
WP :001 IN170x15
PRG:<03ABCDEFG>
S99 T0055s 0360 i
Cyc l e end OK
>WP :001IN170x15
PRG:<03ABCDEFG>
F r i 05 Jan 2007
11:49
WP :001 IN170x15
PRG:<03ABCDEFG>
S05 T0015s 0124 i
Manua l down s l op e
>WP :001IN170x15
PRG:<03ABCDEFG>
F r i 05 Jan 2007
11:49
BT1
During a gas and water fl ow rate test. The
message disappears when the button is
released to be replaced by the names of
the WP and the program.
Display during the end of a cycle
which has executed correctly.
Pressing BT 1 displays the end
of installation screen indicating
the WP and the program.
Display during the end of cycle
caused by the slope down key
(BT 13). Pressing BT 1 displays
the end of installation screen
indicating the WP and the
program.
BT1
