Polysoude P6 - Weld Cycle Display Information; Display During Cycle and Parameter Overrides

THE ART OF WELDING
P6
PN-0509076 Rev. 16 53-92
Examples of displayed messages during a weld cycle:
WP :001 IN170x15
PRG:<03ABCDEFG>
S05 T0015s 0124 i
*!* 12.3V 150.0A
V32=0125 mm/mi n
S05 T0015s 0124 i
*!* 12.3V 150.0A
I22=112 A
S05 T0015s 0124 i
*!* 12.3V 150.0A
WP :001 IN170x15
PRG:<03ABCDEFG>
S05 T0055s 0360 i
Cyc l e end
The display during a cycle shows:
on the fi rst two rows, the WP •
and the current program,
on the third row, the number of •
the current sector, elapsed time
and the movement pulses,
on the fourth row, 2 stars (1Hz) •
encircling an exclamation mark,
the arc voltage and welding cur-
rent (I22).
Changing a speed override erases
the fi rst two rows and displays the
new values sent. After 5 seconds,
the standard display shown during a
cycle reappears.
Changing a current override erases
the fi rst two rows and displays the
new values sent. After 5 seconds,
the standard display shown during a
cycle reappears.
A stop or slope down caused during
a cycle displays the corresponding
message.
