9-- 7
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
The Output screen shows the phase-to-neutral voltage, phase current, and
frequency, being supplied by the UPS, followed by the KVA, KW, and power factor
measurements.
OUTPUT
VA
VB VC
KVA KW PF
IA IB IC
***
*** *** ***
******
*** ******
FREQ
***
SYSTEM
Figure 9---8. Output Meter Screen
The Bypass screen shows the phase-to-neutral voltage, and frequency of the
bypass source.
Freq
BYPASS
VA
VB VC
*** *** *** ***
SYSTEM
F i g u r e 9 --- 9 . B y p a s s M e t e r S c r e e n
