POWER WIRING INSTALLATION NOTES
164201300---1
A --- 1 5
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
Table T. Power Cable Conduit Requirements Powerware 9330 (25 kVA--30 kVA)
Powerware
System
Voltage Terminal
Number of
Wires in
Conduit
Minimum
Conduit
Trade Size
(inches)
Number of
Conduits
AC Input to UPS
(A,B,C,Gnd)
4 1-1/4 1
9330-40/25
208/220
AC
AC Input to Bypass
(A,B,C,Neut,Gnd)
5 1-1/4 1
A
C
Output
(A,B,C,Neut,Gnd)
5 1-1/4 1
AC Input to UPS
(A,B,C,Gnd)
4 3/4 1
9330---40/25
480
AC
AC Input to Bypass
(A,B,C,Neut,Gnd)
5 3/4 1
C
Output
(A,B,C,Neut,Gnd)
5 3/4 1
AC Input to UPS
(A,B,C,Gnd)
4 1/2 1
9330---40/25
600
AC
AC Input to Bypass
(A,B,C,Neut,Gnd)
5 1/2 1
C
Output
(A,B,C,Neut,Gnd)
N/A N/A N/A
9330---40/25
288
DC
External Battery DC Source
(Positive, Negative, Gnd)
3 1 1
AC Input to UPS
(A,B,C,Gnd)
4 1-1/4 1
9330-40/30
208/220
AC
AC Input to Bypass
(A,B,C,Neut,Gnd)
5 1-1/2 1
C
Output
(A,B,C,Neut,Gnd)
5 1-1/2 1
AC Input to UPS
(A,B,C,Gnd)
4 3/4 1
9330-40/30
480
AC
AC Input to Bypass
(A,B,C,Neut,Gnd)
5 3/4 1
C
Output
(A,B,C,Neut,Gnd)
5 3/4 1
AC Input to UPS
(A,B,C,Gnd)
4 1/2 1
9330-40/30
600
AC
AC Input to Bypass
(A,B,C,Neut,Gnd)
5 1/2 1
C
Output
(A,B,C,Neut,Gnd)
N/A N/A N/A
9330---40/30
288
DC
External Battery DC Source
(Positive, Negative, Gnd)
3 1 1
