Powerware 9330 - Page 192

DESCRIPTION:
DATE:
DRAWING NO:
17 of 17
SHEET:
REVI SION:
L
041503
164201300---1
POWER WIRING INSTALLATION NOTES
A --- 1 8
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
16. Bypass and output overcurrent protection and bypass and output disconnect switches are
to be provided by the user. Table W lists the maximum rating for bypass and output circuit
breakers satisfying the criteria for both.
Table W. Maximum Bypass and Output Circuit Breaker Ratings
P
o
w
e
r
w
a
r
e
S
y
s
t
e
m
Output Voltage Rating
P
owe
r
wa
r
e
S
y
s
t
em
208/220V 480V 600V
9330---20/10 35 15 15
9330---20/15 60 25 20
9330---20/20 70 30 25
9330---40/25 90 40 30
9330---40/30 110 45 40
9330---40/35 125 60 45
9330---40/40 150 60 50
17. Battery voltage is computed at 2 volts per cell as defined by Article 480 of the NEC.
Rated battery current is computed at the computed voltage.
