DESCRIPTION:
DATE:
DRAWING NO: SHEET:
REVI SION:
G
3of5
061502
CUSTOMER INTERFACE WIRING
INSTALLATION NOTES
CSB CUSTOMER INTERFACE
X-SLOT 2 RIBBON CONNECTOR
X-SLOT 4 RIBBON CONNECTOR
X-SLOT 3 RIBBON CONNECTOR
X-SLOT 1 RIBBON CONNECTOR
164201300---2
(AS-400 Slot)
REFER TO DRAWING 164201300--- 8
FOR LOCATION OF CSB
SERIAL PORT
COMMUNICATIONS SERVER BOARD (CSB)
A --- 2 1
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
