DESCRIPTION:
DATE:
DRAWING NO:
4of5
SHEET:
REVI SION:
G
051502
CUSTOMER INTERFACE WIRING
INSTALLATION NOTES
164201300---2
A --- 2 2
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
Table Y. Summary Alarm Relay Contacts
2
1
3
2
1
3
RELAY 1
RELAY 2
CONTACT RATING:
Maximum Switched Voltage: 120 VAC Maximum Carrying Current: 5A
NOTE: Relays are shown in de-energized state. Relays change state
when the UPS is in normal operating mode.
