PHYSICAL FEATURES AND REQUIREMENTS
164201300---3
A --- 2 5
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
6. The basic environmental requirements for operation of the UPS system are:
Ambient Temperature Range: 0 --- 4 0 ˚C (32---104˚F)
Recommended Operating Range: 20---25˚C (68---77˚F)
Maximum Relative Humidity: 95%, noncondensing
The UPS ventilation requirements are shown in Table AC.
Tabl e AC. Air Conditioning or Ventilation Requirements
During Full Load Operation
Powerware 9330 (10 kVA--40 kVA)
Ratings Input/Output Voltage
Heat Rejection*
BTU/hr ¢ 1000/hr (Kg---cal/hr)
208/208, 208/220, 220/208, 220/220 2.1 (0.53)
10 KVA
480/208, 600/208 2.7 (0.7)
480/480 3.6 (0.9)
208/208, 208/220, 220/208, 220/220 3.1 (0.8)
15 KVA
480/208, 600/208 4.0 (1.1)
480/480 5.3 (1.3)
208/208, 208/220, 220/208, 220/220 4.2 (1.1)
20 KVA
480/208, 600/208 5.4 (1.4)
480/480 7.1 (1.8)
208/208, 208/220, 220/208, 220/220 5.2 (1.3)
25 KVA
480/208, 600/208 6.7 (1.7)
480/480 8.9 (2.2)
208/208, 208/220, 220/208, 220/220 6.3 (1.6)
30 KVA
480/208, 600/208 8.0 (2.0)
480/480 10.7 (2.7)
208/208, 208/220, 220/208, 220/220 7.3 (1.8)
35 KVA
480/208, 600/208 9.3 (2.4)
480/480 12.5 (3.1)
208/208, 208/220, 220/208, 220/220 8.3 (2.1)
40 KVA
480/208, 600/208 10.7 (2.7)
480/480 14.3 (3.6)
