A --- 6 4
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
DESCRIPTION:
DATE:
DRAWING NO: SHEET:
REVI SION:
N
LOCATION OF OPTIONS CABINET TERMINALS
2of6
013004
OPTIONS CABINET WITH OPTIONAL DI STRI BUTI ON HOUSING
FRAME GROUND TERMINAL
42 CIRCUIT
DISTRIBUTION PANEL
MAINTENANCE BYPASS
SWITCH (MBS )
BYP ASS
BREAKER
AC OUTPUT
BREAKER
TERMINALS
POWERWARE 9330 (10 kVA-- 20 kVA)
(USE SQUA RE---D TYPE
QO OR QOB BREAKERS)
OUTPUT POWER CORD WITH
RECEPTICAL. (INSTALLATION
OF THIS CABLE ASSEMBLY
SHALL BE INACCORDANCE
WITH ARTICLE 356 OF THE
NEC.)
OPTIONAL DISTRIBUTION HOUSING
164201300---10
