A --- 7 2
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
DESCRIPTION:
DATE:
DRAWING NO: SHEET:
REVI SION:
D
4of4
053001
LOCATION OF OPTIONS CABINET TERMINALS
OPTIONS CABINET POWER TERMINALS
POWERWARE 9330 (25 kVA-- 40 kVA)
164201300---11
CONDUIT ENTRY AREA FOR
OUTPUT FROM OPTIONAL
DISTRIBUTION PANEL
(REMOVE PANEL TO DRILL OR
PUNCH CONDUIT HOLES.)
CONDUIT ENTRY AREA
FOR AC INPUT AND
OUTPUT CONNECTIONS
(REMOVE PANEL TO DRILL
OR PUNCH CONDUIT
HOLES.)
