A --- 7 3
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
DESCRIPTION:
DATE:
DRAWING NO: SHEET:
REVI SION:
J
LOCATION OF BATTERY CABINET TERMINALS
1of1
101502
BATTERY CABINET TERMINALS
BATTERY
BREAKER
EXTERNAL BATTERY CABINET
POWER CO NNECTO R FOR
ADDITIONAL BATTERY CABINET
CONNECTION
POWERWARE 9330 (10 kVA-- 20 kVA)
164201300---12
POWERWARE 9330 (25 kVA-- 40 kVA)
