AFV
+
Series High Power Programmable AC Power Supply
1-5
Current Range (RMS)
0-83.3A
0-125A
0-166.7A
0-250A
0-375A
0-500A
0-625A
0-833.3A
0-1000A
0-1250A
Current
Resolution(RMS)
0.1A
Current Accuracy
(RMS)
0.5% F.S.
+
4 counts
Power Range
0-10kW
0-15kW
0-20kW
0-30kW
0-45kW
0-60kW
0-75kW
0-100kW
0-120kW
0-150kW
Power Resolution
0.1kW
Power Accuracy
1% F.S.+6 counts
GENERAL
Efficiency
≥90% at Max. Power
≥85% at Max. Power
HMI
Touch Screen, 7" Color TFT LCD
Program Mode
STEP : 24 sets / 255 cycles. (Volt./Freq./Time)
RAMP : 12 sets / 255 cycles. (Volt./Freq./Time)
Soft Start
Setting : Rated Volt. / Rated Freq. / Start Volt. / Start Freq. / Delay Time / Ramp Time
Protection
Input : Input N.F.B, Over Voltage, Under Voltage,
Output : Over Voltage, Over Current, Reverse Current, Over Temperature
and machine will display the error code and give a warning sound.
Remote Interface
Standard : RS-232/RS-422/RS-485 Option : GPIB, Ethernet
Operational
Temperature
0℃ ~45℃
Humidity
0~90% ( Non condensing )
Altitude
< 1,500m
Dimensions (H x W x
D)
1045 * 628
* 840mm
(including
wheel)
1440 * 628 * 840 mm (including
wheel)
1645 * 828 * 840
mm((including wheel)
1900 * 1178 * 1200 mm
Weight
230kg
280kg
320kg
450kg
580kg
670kg
710kg
980kg
1135kg
1415kg
*1 Please contact for other voltage specification.
*2 The rated input voltage is 380V。
*3 For type A(45-500Hz) and output power 20kVA and over models, the output power will be influenced by the
frequency characteristic curve.
*4 Low : 90 - 140V or High 180 - 280V 。
*All specification are subject to change without notice.
Table 1.1 Technical Specifications (single-phase model/10kVA~150KVA)
