Preen AFV+ Series - Page 18

AFV
+
Series High Power Programmable AC Power Supply
1-6
Model
AFV-PLUS
-33010
AFV-PLUS
-33015
AFV-PLUS
-33020
AFV-PLUS
-33030
AFV-PLUS
-33045
AFV-PLUS
-33060
AFV-PLUS
-33075
AFV-PLUS
-33100
AFV-PLUS
-33120
INPUT
Phase
3Ø / 3 Wire + G
Voltage *1
380V±15%
Frequency
47 - 63Hz
Max. Current *2
18.8A
28.1A
37.5A
56.3A
84.4A
112.5A
140.7A
198.6A
238.3A
Power Factor
≥0.9（Max. Power）
OUTPUT
Power (VA)
Power
(VA)
15kVA
20kVA
30kVA
45kVA
60kVA
75kVA
100kVA
120kVA
Phase
Phase
Voltage
Ranges
Low(V)
0V~155.0V（L-N）
High(V)
0V~310.0V（L-N）
Voltage Resolution
0.1V
Voltage Accuracy
0.5% F.S.+4 counts
Frequency Range*3
Type A: 45~500Hz, Type B: 45-120Hz, Type C: 300-840Hz
Frequency
Resolution
0.1Hz
Frequency Accuracy
±0.02% F.S.
Max.
Current
(RMS)
Low(A)
27.8A
41.7A
55.6A
83.3A
125A
166.7A
208.3A
277.8A
333.3A
High(A)
13.9A
20.8A
27.8A
41.7A
62.5A
83.3A
104.2A
138.9A
166.7A
Line Regulation
< 0.5%
Load Regulation
≦ 0.5% (Resistive Load)
Total Harmonic
Distortion(THD) *4
≦ 0.5% (Resistive Load)
Response Time
≦ 1ms
Crest Factor
≥3
MEASUREMENT
Voltage Range
0V~310.0V
Voltage Resolution
0.1V
Voltage Accuracy
0.5% F.S.+4 counts
Frequency Range
45.0-500.0Hz
Frequency
Resolution
0.01Hz
Frequency Accuracy
±0.02% F.S.
Current Range (RMS)
0 - 27.8A
0 - 41.7A
0 - 55.6A
0 - 83.3A
0 - 125A
0 -
166.7A
0 - 208.3A
0 - 277.8A
0 - 333.3A
Current
Resolution(RMS)
0.1A
Current Accuracy
(RMS)
0.5% F.S.+4 counts
Power Range
0 - 10kW
0 - 15kW
0 - 20kW
0 - 30kW
0 - 45kW
0 - 60kW
0 - 75kW
0 - 100kW
0 - 120kW
