AFV
+
Series High Power Programmable AC Power Supply
1-7
Power Resolution
0.1kW
Power Accuracy
1% F.S.+6 counts
GENERAL
Efficiency
≥90% at Max. Power
≥85% at Max. Power
HMI
Touch Screen, 7" Color TFT LCD
Program Mode
STEP : 24 sets / 255 cycles. (Volt./Freq./Time)
RAMP : 12 sets / 255 cycles. (Volt./Freq./Time)
Soft Start
Setting : Rated Volt. / Rated Freq. / Start Volt. / Start Freq. / Delay Time / Ramp Time
Three Phase
Independent
Adjustment
U-N/V-N/W-N, Adjustment 0-310V
Protection
Input : Input N.F.B, Over Voltage, Under Voltage,
Output : Over Voltage, Over Current, Reverse Current, Over Temperature
and machine will display the error code and give a warning sound.
Remote Interface
Standard : RS-232/RS-422/RS-485 Option : GPIB, Ethernet
Operational
Temperature
0℃ ~45℃
Humidity
0~90% ( Non condensing )
Altitude
< 1,500m
Dimensions (H x W x
D)
1045 *
628 * 840
mm
(including
wheel)
1440 * 628 * 840 mm
(including wheel)
1645 * 828 * 840
mm
(including wheel)
1900 * 1178 * 1200 mm
Weight
280kg
305kg
360kg
400kg
560kg
670kg
960kg
1170kg
1450kg
*1 Please contact for other voltage specification.
*2 The rated input voltage is 380V.
*3 For type A (45-500Hz) and output power 20kVA and over models, the output power will be
influenced by the frequency characteristic curve.
*4 Low : 90 - 140V or High 180 - 280V.
*5 For dimensions and weight of 300kVA and over models, please contact us to confirm.
for AFV
+
series over 300kVA, please contact us for details
* All specification are subject to change without notice.
Table 1.2 Technical Specifications (three-phase model /10kVA~120kVA)
