Preen AFV+ Series - Page 61

AFV
+
Series High Power Programmable AC Power Supply
3-49
Please refer to figure 3.20 for phase angle setting between U phase and V phase. The
setting page also shows the maximum and minimum of set value for the phase angle.
Press to confirm and finish setting. Press to clear all the input value or
press to modify setting.
Figure 3.20 U-V phase angle setting
：Press the value to the phase angle between U phase and w
phase.
Please refer to figure 3.21 for phase angle setting between U phase and W phase.
The setting page also shows the maximum and minimum of set value for the phase
angle. Press to confirm and finish setting. Press to clear all the input
value or press to modify setting.
Figure 3.21 U-W phase angle setting
