139
MBOX® USER MANUAL
Control Parameter Description Units Typical Scale Value
Repeat Y/tY Sets both Y position and texture Y position distances for each
repeat of a repeated screen object, typically used with a xed
offset value only, not live control
Pixels 0 - use offset value
Opacity (Global) Transparency (fade to transparent) of texture on all screen objects 0 - 1.0 0.00390625
Origin X Moves the origin X from the default origin (top left corner) of a
screen object. This is a sticky control
1
Pixels 0 - use offset value
Origin Y Moves the origin Y from the default origin (top left corner) of a
screen object. This is a sticky control
1
Pixels 0 - use offset value
Expand Used to add extra pixels to a screen object’s perimeter to allow
very small screen objects to better visualized
Pixels 0 - use offset value
Red Controls Red subtractive color mixing on the screen object 0 - 1.0 0.00390625
Green Controls Green subtractive color mixing on the screen object 0 - 1.0 0.00390625
Blue Controls Blue subtractive color mixing on the screen object 0 - 1.0 0.00390625
Screen Object Control Types continued...
Note 1: Sticky controls affect the current screen object and all following screen objects until another sticky control of
the same type is used on a following screen object.
Note 2: The X/Y/Z rotations only work if screen objects are converted to 3D vertex screen objects - either Triangle
Strips or Triangle Fans.
