Video and Utility Inputs (Texture Folder 255)
Texture Folder 255 is reserved for special uses such as selecting video/syphon inputs or copying layers.
Texture
Value
Input
0 Patch Info Display
1 Copy Layer 1 FX+
2 Copy Layer 2 FX+
3 Copy Layer 3 FX+
4 Copy Layer 4 FX+
5 Copy Layer 5 FX+
6 Copy Layer 6 FX+
7 Copy Layer 7 FX+
8 Copy Layer 8 FX+
9 Copy Layer 9 FX+
10 Copy Layer 10 FX+
11 Copy Layer 11 FX+
12 Copy Layer 12 FX+
13 Copy Layer 13 FX+
14 Copy Layer 14 FX+
15 Copy Layer 15 FX+
16 Copy Layer 16 FX+
17 Copy Layer 17 FX+
18 Copy Layer 18 FX+
19 Copy Layer 19 FX+
20 Copy Layer 20 FX+
21 Copy Layer 21 FX+
22 Copy Layer 22 FX+
23 Copy Layer 23 FX+
24 Copy Layer 24 FX+
Note: Depending on the product version (Designer/Studio/Mini) there are limits placed on the number of layers, syphon
inputs, and number of video inputs. This table represents the full list of available inputs for Mbox Designer. Studio has
12 layers, and Mini has 6. Therefore, the Copy Layer values will be limited to those maximums for each. Studio has 4
Syphon inputs, and Mini has 2. Therefore, the Syphon Input values will be limited to those maximums for each. Studio
has 4 video inputs, and Mini has 2. Therefore, the video input values will be limited to those maximums for each.
Texture
Value
Input
31 Copy Layer 1 Raw
32 Copy Layer 2 Raw
33 Copy Layer 3 Raw
34 Copy Layer 4 Raw
35 Copy Layer 5 Raw
36 Copy Layer 6 Raw
37 Copy Layer 7 Raw
38 Copy Layer 8 Raw
39 Copy Layer 9 Raw
40 Copy Layer 10 Raw
41 Copy Layer 11 Raw
42 Copy Layer 12 Raw
43 Copy Layer 13 Raw
44 Copy Layer 14 Raw
45 Copy Layer 15 Raw
46 Copy Layer 16 Raw
47 Copy Layer 17 Raw
48 Copy Layer 18 Raw
49 Copy Layer 19 Raw
50 Copy Layer 20 Raw
51 Copy Layer 21 Raw
52 Copy Layer 22 Raw
53 Copy Layer 23 Raw
54 Copy Layer 24 Raw
201 Syphon Input 1
202 Syphon Input 2
203 Syphon Input 3
204 Syphon Input 4
Texture
Value
Input
205 Syphon Input 5
206 Syphon Input 6
207 Syphon Input 7
208 Syphon Input 8
209 Syphon Input 9
210 Syphon Input 10
211 Syphon Input 11
212 Syphon Input 12
231 CG Black Rectangle
232 CG White Rectangle
233 CG Red Rectangle
234 CG Green Rectangle
235 CG Blue Rectangle
236 CG Cyan Rectangle
237
CG Magenta
Rectangle
238 CG Yellow Rectangle
241 Video Input 1
242 Video Input 2
243 Video Input 3
244 Video Input 4
245 Video Input 5
246 Video Input 6
247 Video Input 7
248 Video Input 8
254 CG Color Bars
255 Null Image
