PRG Mbox - Output Master Effect [Designer(2);Studio(1);Mini(1)]; Output Master Camera [Designer Only]; Output Master Geometry [Designer;Studio Only]

183
MBOX® USER MANUAL
Chan Size Function Default Snap Notes
1 1 Effect Select 0 Y see Combined Effects
2 1 Modier 1 0 N
3 1 Modier 2 0 N
4 1 Modier 3 0 N
5 1 Modier 4 0 N
6 1 Modier 5 0 N
6 Total Channels
Output Master Effect [Designer(2)/Studio(1)/Mini(1)]
Chan Size Function Default Snap Notes
1 1
Enable Projection
Camera
0 Y
Value of 0 applies DMX controls, 255 applies
Projection Mapping Camera matrix from Mbox
Remote
2 2 Position X 32767 N
4 2 Position Y 32767 N
6 2 Position Z 42767 N Note: non-standard default
8 2 Lookat X 32767 N
10 2 Lookat Y 32767 N
12 2 Lookat Z 32767 N
14 1 Field of View 71 N Note: non-standard default
15 2 Roll 32767 N
16 Total Channels
Output Master Camera [Designer only]
Chan Size Function Default Snap Notes
1 1 Output Position X 32767 Y
3 2 Output Position Y 32767 N
5 2 Output Scale 32767 N
7 2 Output Rotation 32767 N
9 2 Mix Offset X 32767 N
11 2 Mix Offset Y 32767 N
12 Total Channels
Output Master Geometry [Designer/Studio only]
