MBOX® USER MANUAL
Chan Size Function Default Snap Notes
1 1 Effect Select 0 Y see Combined Effects
2 1 Modier 1 0 N
3 1 Modier 2 0 N
4 1 Modier 3 0 N
5 1 Modier 4 0 N
6 1 Modier 5 0 N
6 Total Channels
Layer Effect [Designer(4)/Studio(2)/Mini(1)]
Chan Size Function Default Snap Notes
1 1 Layer Volume 255 N
1 Total Channels
Layer Volume [Designer/Studio/Mini]
Chan Size Function Default Snap Notes
1 1 Hours 0 N maximum of 23
2 1 Minutes 0 N maximum of 59
3 1 Seconds 0 N maximum of 59
4 1 Frames 0 N maximum of 29
4 Total Channels
Layer DMX Timecode [Designer/Studio/Mini]
Chan Size Function Default Snap Notes
1 1 Mode 0 Y see Pixel Mapping Group Control Modes
2 1 Intensity 255 N
3 1 Red/Cyan 255 N
4 1 Green/Magenta 255 N
5 1 Blue/Yellow 255 N
5 Total Channels
Pixel Mapping Group Control [Designer/Studio/Mini]
