PRG Mbox - Output Master Shutter [Designer]; Output Master Shutter [Studio]

185
MBOX® USER MANUAL
Chan Size Function Default Snap Notes
1 1 Shape 0 Y see Shutter Mode/Shapes
2 1 Red 0 N Additive
3 1 Green 0 N Additive
4 1 Blue 0 N Additive
5 1 Edge Softness 0 N
6 1 Shutter 1a 0 N
7 1 Shutter 1b 0 N
8 1 Shutter 2a 0 N
9 1 Shutter 2b 0 N
10 1 Shutter 3a 0 N
11 1 Shutter 3b 0 N
12 1 Shutter 4a 0 N
13 1 Shutter 4b 0 N
14 2 X Position 32767 N
16 2 Y Position 32767 N
18 2 Scale 65535 N
20 1 Rotation 127 N
21 1 Damping 0 N
21 Total Channels
Output Master Shutter [Designer]
Chan Size Function Default Snap Notes
1 1 Shape 0 Y
see Shutter Mode/Shapes
2 1 Red 0 N Additive
3 1 Green 0 N Additive
4 1 Blue 0 N Additive
5 1 Edge Softness 0 N
6 1 Shutter 1a 0 N
7 1 Shutter 1b 0 N
8 1 Shutter 2a 0 N
9 1 Shutter 2b 0 N
10 1 Shutter 3a 0 N
11 1 Shutter 3b 0 N
12 1 Shutter 4a 0 N
13 1 Shutter 4b 0 N
13 Total Channels
Output Master Shutter [Studio]
