180
MBOX® USER MANUAL
Start Size Type Sub-Type Universe
1 5 Global Master
1st
113 Total
Channels
(1 Master)
6 9 Light 1
15 9 Light 2
24 9 Light 3
33 9 Light 4
42 9 Light 5
51 6 Output Master 1 Base
57 6 FX
63 12 Geometry
75 26 Keystone
101 13 Shutter
Up to 7 additional Output Masters may be added,
63 channels each, using consecutive universes as necessary.
1 41 Layer 1 Base
Next
Universe
after Masters
464 Total
Channels
(8 Layers)
42 6 FX 1
48 6 FX 2
54 1 Audio Volume
55 4 DMX Timecode
59 58 Layer 2
117 58 Layer 3
175 58 Layer 4
233 58 Layer 5
291 58 Layer 6
349 58 Layer 7
407 8 Layer 8
Up to 4 additional Layers may be added,
58 channels each, using the next consecutive universe.
Summary: Mbox Studio
