PRG Mbox - Fixture Parameter Data; Global Master [Designer;Studio;Mini]; Light [Designer;Studio Only]; Output Master Base [Designer;Studio;Mini]

182
MBOX® USER MANUAL
Chan Size Function Default Snap Notes
1 1 Intensity 255 N Overall Dimming (in IO Module if present)
2 1 Control 0 Y
see Global Master Control Channel
3 1 Control Selector 0 Y Modier for control macros
4 1
Pixel Mapping
Intensity
255 N Master level for pixel mapping output
5 1 Master Volume 255 N Master level for all audio output
5 Total Channels
Global Master [Designer/Studio/Mini]
Chan Size Function Default Snap Notes
1 1 Intensity 255 N
2 1 Red 255 N
3 1 Green 255 N
4 1 Blue 255 N
5 1 Ambience 255 N
6 2 Horizontal Bearing 32767 N
8 2 Vertical Bearing 32767 N
9 Total Channels
Light [Designer/Studio only]
Chan Size Function Default Snap Notes
1 1 Intensity 255 N Software dimming of output
2 1 Red 127 N Subtractive 0-126, Additive 128-255
3 1 Green 127 N Subtractive 0-126, Additive 128-255
4 1 Blue 127 N Subtractive 0-126, Additive 128-255
5 1 Brightness 127 N
6 1 Contrast 127 N
6 Total Channels
Output Master Base [Designer/Studio/Mini]
The data in these charts is organized by xtures and/or sub-xture components. See tables beginning on page 48 for
information on how sub-xtures are combined into xtures. In some cases, PRG recommends combining sub-xtures
(e.g. the Layer xture) to create one xture rather than several.
Note: The following tables show combined information for Designer, Studio, and Mini. The applicable version is noted in
the title for each table (e.g. [Designer/Studio]) and in the case of effects, the differing quantities of each item per product
version are noted in parentheses (e.g. [Designer(2)/Studio(1)/Mini(1)] ).
FIXTURE PARAMETER DATA
