PRG Mbox - Layer Base [Designer]

187
MBOX® USER MANUAL
Chan Size Function Default Snap Notes
1 1 Opacity 0 N
2 1 Red 127 N Subtractive 0-126, Additive 128-255
3 1 Green 127 N Subtractive 0-126, Additive 128-255
4 1 Blue 127 N Subtractive 0-126, Additive 128-255
5 1 Brightness 127 N
6 1 Contrast 127 N
7 1 Texture Folder 0 Y
Folder 255: see Video and Utility Inputs
8 1 Texture File 0 Y
9 1 Play Mode 0 Y
see Play Modes
10 1 Play Speed 127 N
see Play Speed
11 2 In Frame 0 N
13 2 Out Frame 65535 N
15 1 Sync Stream 0 Y
see Sync Streams
16 1 Sync Offset 0 N
17 1 Aspect Ratio 0 N
see Aspect Control
18 1 Frame Blending 255 N
see Frame Blending Control
19 1 Texture Xfade Type 0 Y
see Texture Transitions
20 1 Texture Xfade Time 0 Y
21 1 Object Folder 0 Y
22 1 Object File 0 Y
23 1 Object Xfade Type 0 Y
see Object Transitions
24 1 Object Xfade Time 0 Y
25 2 X Position 32767 N
27 2 Y Position 32767 N
29 2 Z Position 32767 N
31 2 Scale 32767 N
33 2 X Scale 32767 N
35 2 Y Scale 32767 N
37 2 Z Scale 32767 N
39 2 Z Rotation 32767 N
41 2 X Rotation 32767 N
43 2 Y Rotation 32767 N
45 1 Z Spin 127 N
46 1 X Spin 127 N
47 1 Y Spin 127 N
48 1 Mix Select 0 Y
49 1 Mix Mode 0 Y
see Layer Mix Modes
50 1 Blend Mode 0 Y
see Blend Modes
51 1 Draw Mode 0 Y
see Draw Modes
52 1 Image Remap 0 Y
52 Total Channels
Layer Base [Designer]
